Caching Strategies That Actually Work

●TL;DR

Caching is a solved problem that teams keep solving wrong. The pattern I see repeatedly: Redis cache in front of PostgreSQL, no invalidation strategy, stale data for 5-30 minutes after writes, and support tickets asking "why doesn't my change show up?" The fix is a multi-layer caching architecture with explicit invalidation at each layer. Application-level cache with write-through invalidation handles 80% of cases. CDN edge caching handles the other 20%. Redis is rarely the right first choice for SaaS applications... HTTP caching headers and in-process caches (Map, LRU) eliminate 60-80% of database queries without the operational overhead of a cache cluster. When you do need Redis, use it for session state and rate limiting, not as a general-purpose query cache.

Part of the Performance Engineering Playbook ... a comprehensive guide to building systems that stay fast under real-world load.

●The Caching Pyramid

Most teams reach for Redis first. This is backwards. The most effective caching strategy uses multiple layers, each with different performance characteristics and invalidation costs.

┌────────────────────────────┐
│      Browser Cache         │  ← Fastest (0ms), hardest to invalidate
├────────────────────────────┤
│      CDN / Edge Cache      │  ← 5-20ms, stale-while-revalidate
├────────────────────────────┤
│   In-Process Cache (LRU)   │  ← 0.01ms, eviction-based
├────────────────────────────┤
│   Distributed Cache (Redis)│  ← 1-5ms, explicit invalidation
├────────────────────────────┤
│       Database             │  ← 5-50ms, source of truth
└────────────────────────────┘

Start at the top. Each layer you skip means unnecessary latency and infrastructure.

●Layer 1: HTTP Cache Headers (Free Performance)

Before writing a single line of caching code, configure your HTTP cache headers correctly. This alone eliminates 30-60% of requests to your origin server.

Static Assets

// Next.js: static assets get immutable caching automatically
// For custom routes serving static content:
export async function GET() {
	const data = await getStaticContent();

	return Response.json(data, {
		headers: {
			"Cache-Control": "public, max-age=31536000, immutable",
			ETag: generateETag(data),
		},
	});
}

immutable tells the browser: this content will never change at this URL. Use content-hashed URLs (style.a1b2c3.css) for truly immutable assets. This eliminates revalidation requests entirely.

Dynamic API Responses

// SaaS dashboard: data that changes infrequently
export async function GET(request: Request) {
	const tenantId = getTenantId(request);
	const dashboardData = await getDashboardMetrics(tenantId);

	return Response.json(dashboardData, {
		headers: {
			// Private: only browser caches, not CDN (tenant-specific data)
			"Cache-Control": "private, max-age=60, stale-while-revalidate=300",
			ETag: generateETag(dashboardData),
		},
	});
}

The stale-while-revalidate directive is the most underused caching feature. It tells the browser: "serve the stale response immediately, then revalidate in the background." Users get instant responses while the cache refreshes asynchronously.

The Cache-Control Decision Matrix

●Layer 2: In-Process Cache (Zero Latency)

An in-process cache... a Map or LRU cache in your application's memory... has zero network latency. For data that's read frequently and changes infrequently, this is faster than Redis by 100-1000x.

import { LRUCache } from "lru-cache";

const configCache = new LRUCache<string, TenantConfig>({
	max: 10000, // Maximum 10K entries
	ttl: 1000 * 60 * 5, // 5-minute TTL
	updateAgeOnGet: true, // Reset TTL on read
});

async function getTenantConfig(tenantId: string): Promise<TenantConfig> {
	const cached = configCache.get(tenantId);
	if (cached) return cached;

	const config = await db.query("SELECT * FROM tenant_configs WHERE tenant_id = $1", [tenantId]);

	configCache.set(tenantId, config);
	return config;
}

// Invalidate on write
async function updateTenantConfig(tenantId: string, updates: Partial<TenantConfig>) {
	await db.query("UPDATE tenant_configs SET config = $1 WHERE tenant_id = $2", [updates, tenantId]);

	// Immediate invalidation ... next read hits the database
	configCache.delete(tenantId);
}

When In-Process Cache Fails

Multi-instance deployments. If your application runs on 4 instances behind a load balancer, each instance has its own cache. A write on instance 1 doesn't invalidate the cache on instances 2-4. Users get inconsistent data depending on which instance serves their request.

Solutions by complexity:

For most SaaS applications, a 30-60 second TTL is sufficient. Users don't expect real-time updates on configuration pages... they expect changes to take effect "soon."

●Layer 3: Redis (When You Actually Need It)

Redis is an excellent tool for specific use cases. It's a terrible general-purpose query cache for SaaS applications.

Good Redis Use Cases

Session storage:

// Session store with Redis ... user state across instances
async function getSession(sessionId: string): Promise<Session | null> {
	const data = await redis.get(`session:${sessionId}`);
	if (!data) return null;

	// Extend session TTL on every access
	await redis.expire(`session:${sessionId}`, 3600);
	return JSON.parse(data);
}

Rate limiting:

// Sliding window rate limiter
async function checkRateLimit(
	userId: string,
	limit: number,
	windowMs: number
): Promise<{ allowed: boolean; remaining: number }> {
	const key = `rate:${userId}`;
	const now = Date.now();
	const windowStart = now - windowMs;

	const pipeline = redis.pipeline();
	pipeline.zremrangebyscore(key, 0, windowStart);
	pipeline.zadd(key, now, `${now}`);
	pipeline.zcard(key);
	pipeline.expire(key, Math.ceil(windowMs / 1000));

	const results = await pipeline.exec();
	const count = results[2][1] as number;

	return {
		allowed: count <= limit,
		remaining: Math.max(0, limit - count),
	};
}

Pub/sub for cache invalidation:

// Publisher: invalidate cache across all instances
async function invalidateCache(key: string) {
	await redis.publish(
		"cache-invalidation",
		JSON.stringify({
			key,
			timestamp: Date.now(),
		})
	);
}

// Subscriber: each application instance listens
redis.subscribe("cache-invalidation", (message) => {
	const { key } = JSON.parse(message);
	localCache.delete(key);
});

Bad Redis Use Cases

General query caching where the invalidation logic is more complex than the original query:

// BAD: caching a complex query result in Redis
async function getOrderSummary(tenantId: string) {
	const cached = await redis.get(`orders:summary:${tenantId}`);
	if (cached) return JSON.parse(cached);

	const summary = await db.query(
		`
    SELECT status, COUNT(*), SUM(total)
    FROM orders WHERE tenant_id = $1
    GROUP BY status
  `,
		[tenantId]
	);

	// How do you invalidate this?
	// - When an order is created?
	// - When an order status changes?
	// - When an order total is modified?
	// - When an order is deleted?
	// Every write to the orders table potentially invalidates this cache.
	await redis.set(`orders:summary:${tenantId}`, JSON.stringify(summary), "EX", 300);

	return summary;
}

This creates a cache that's stale 80% of the time and correct 20% of the time. The TTL-based invalidation means users see data that's up to 5 minutes old. Support tickets follow.

The better approach: Optimize the query itself. Add appropriate indexes. Use materialized views if the aggregation is expensive. The database is already good at this... you don't need to outsource the problem to Redis.

●Cache Invalidation Patterns

Cache invalidation is genuinely hard, but the difficulty is proportional to the pattern you choose.

Write-Through (Simplest)

Every write updates both the database and the cache atomically. The cache is always current.

async function updateUser(userId: string, data: UserUpdate) {
	// Update database
	const user = await db.query("UPDATE users SET name = $1, email = $2 WHERE id = $3 RETURNING *", [
		data.name,
		data.email,
		userId,
	]);

	// Update cache with fresh data
	await cache.set(`user:${userId}`, user);

	return user;
}

Downside: Every write pays the cache update cost even if nobody reads the value before the next write.

Write-Behind (More Complex)

Writes update the cache immediately and asynchronously flush to the database.

I don't recommend this for SaaS applications. The risk of data loss during cache failures is too high for business-critical data. Use write-through or invalidate-on-write instead.

Event-Based Invalidation

For multi-layer caches, use database triggers or application events to invalidate all cache layers:

// Event-based cache invalidation across all layers
class CacheInvalidator {
	private layers: CacheLayer[];

	constructor(layers: CacheLayer[]) {
		this.layers = layers;
	}

	async invalidate(pattern: string) {
		await Promise.all(this.layers.map((layer) => layer.invalidate(pattern)));
	}
}

// Usage
const invalidator = new CacheInvalidator([
	new LocalCacheLayer(localLRU),
	new RedisCacheLayer(redis),
	new CDNCacheLayer(cloudflareApi),
]);

// After any order modification
orderEvents.on("order.updated", async (orderId, tenantId) => {
	await invalidator.invalidate(`order:${orderId}`);
	await invalidator.invalidate(`orders:list:${tenantId}`);
});

●The Metrics That Matter

Cache Hit Rate

Target: 90%+ for application caches, 95%+ for CDN.

// Track cache hit/miss rates
let hits = 0;
let misses = 0;

function getCached(key: string) {
	const value = cache.get(key);
	if (value) {
		hits++;
		return value;
	}
	misses++;
	return null;
}

// Expose as a metric
function getCacheHitRate(): number {
	const total = hits + misses;
	return total === 0 ? 0 : hits / total;
}

A hit rate below 80% means your TTL is too short, your cache is too small, or you're caching the wrong things.

Cache Miss Penalty

The time difference between a cache hit and a cache miss. If your cache miss takes 500ms and your cache hit takes 5ms, your cache miss penalty is 495ms. Users who experience a cache miss get a 100x slower response.

Stale Data Window

The maximum time between a write and when all caches reflect the update. For most SaaS applications, a 5-second stale window is acceptable. For financial data or inventory systems, it needs to be under 1 second.

●When to Apply This

• Your database query latency exceeds 50ms on frequently accessed endpoints
• The same data is read 10x or more for every write
• Your application serves 1,000+ requests per second on read-heavy endpoints
• You're hitting database connection limits during traffic spikes

●When NOT to Apply This

• Your application is write-heavy (caches get invalidated faster than they're read)
• Your data changes every request (real-time streaming, live collaboration)
• Your database handles the load comfortably with proper indexing
• You have fewer than 100 concurrent users
