LLM Integration Architecture: From Vector Databases to Production

●TL;DR

Vector databases: pgvector for < 1M vectors, Qdrant for 1-10M, Pinecone for > 10M or managed preference. RAG retrieval quality matters more than model choice. Embedding models: text-embedding-3-small ($0.02/1M tokens) beats ada-002 at half the cost. Prompt versioning is non-negotiable. Cache aggressively... semantic caching can cut LLM costs by 40-60%. Build fallback chains, not single points of failure.

Part of the AI-Assisted Development Guide ... from code generation to production LLMs.

●Beyond the Demo

Every AI demo looks impressive. GPT-4 answering questions about your documents. Semantic search finding relevant content. Chatbots that seem to understand context.

Then you deploy to production.

Latency spikes to 3 seconds. Costs hit $500/day. Users report hallucinations. Rate limits throttle your application. The vector database times out under load.

The gap between "working demo" and "production system" in LLM integration is wider than most teams expect. This post covers the architecture decisions that bridge that gap... the infrastructure choices, retrieval strategies, and reliability patterns that separate AI features that ship from AI features that get reverted.

I've built LLM integrations serving 100K+ daily queries. The patterns here come from production incidents, cost optimization sessions, and the slow accumulation of what actually works versus what looks good in a pitch deck.

●Vector Database Selection

The vector database is the foundation of any retrieval-augmented generation (RAG) system. Choose wrong and you're either over-paying or under-performing.

The Options

pgvector: The Boring Choice That Works

If you're already running PostgreSQL... and you should be... pgvector is the default choice up to about 1 million vectors.

-- Enable the extension
CREATE EXTENSION IF NOT EXISTS vector;

-- Create a table with embeddings
CREATE TABLE documents (
  id SERIAL PRIMARY KEY,
  content TEXT NOT NULL,
  embedding vector(1536),  -- OpenAI ada-002 dimension
  metadata JSONB
);

-- Create an HNSW index for fast similarity search
CREATE INDEX ON documents
USING hnsw (embedding vector_cosine_ops)
WITH (m = 16, ef_construction = 64);

The advantages are substantial:

• Single database: No additional infrastructure to manage
• ACID transactions: Embeddings and metadata stay consistent
• Familiar tooling: Standard SQL, Prisma support, existing backups
• Cost: Already paying for PostgreSQL

The limitations become apparent at scale. HNSW indexes consume significant memory... roughly 1.5GB per million 1536-dimensional vectors. Query performance degrades as you approach the memory limit.

Recommendation: Start with pgvector. Migrate when you hit performance walls or exceed 1-2 million vectors.

Qdrant: The Performance Sweet Spot

Qdrant offers the best balance of performance, features, and operational complexity for medium-scale deployments.

from qdrant_client import QdrantClient
from qdrant_client.models import Distance, VectorParams, PointStruct

client = QdrantClient("localhost", port=6333)

# Create collection with optimized settings
client.create_collection(
    collection_name="documents",
    vectors_config=VectorParams(
        size=1536,
        distance=Distance.COSINE,
    ),
    optimizers_config={
        "memmap_threshold": 20000,  # Use disk for large segments
        "indexing_threshold": 10000,
    }
)

Key advantages:

• Filtering during search: Native support for metadata filtering without post-processing
• Payload storage: Store full documents alongside vectors
• Quantization: Binary and scalar quantization reduce memory by 4-32x
• Self-hostable: Run on your infrastructure with Docker

Self-hosting Qdrant on a $40/month Hetzner box handles 10 million vectors with sub-20ms queries. Compare that to Pinecone's pricing at scale.

Pinecone: Pay for Simplicity

Pinecone makes sense when:

• You need > 10 million vectors
• You want zero ops overhead
• Your budget accommodates $0.096 per million read units

The managed service handles scaling, replication, and monitoring. You get a REST API and move on with your life.

The tradeoff: vendor lock-in and costs that scale linearly with usage. At 100 million queries/month, you're looking at $9,600 just for reads.

The Decision Framework

< 500K vectors, already on PostgreSQL → pgvector
500K - 10M vectors, ops capability → Qdrant (self-hosted)
500K - 10M vectors, no ops team → Qdrant Cloud or Weaviate Cloud
> 10M vectors, enterprise budget → Pinecone or Milvus
Development/prototyping → Chroma (embedded)

●Embedding Strategy

Your embedding model and chunking strategy determine retrieval quality more than any other factor. A mediocre LLM with excellent retrieval beats a great LLM with poor retrieval.

Model Selection

Default choice: text-embedding-3-small. Half the cost of ada-002 with better performance. The 1536 dimensions are sufficient for most use cases.

For maximum quality: Voyage AI's voyage-large-2 consistently wins benchmarks. Worth the extra $0.02/1M tokens for high-stakes retrieval.

For cost-sensitive applications: Self-host BGE-large-en or E5-large. A single A10G GPU handles 100+ embeddings/second. Monthly cost: ~$150 vs. thousands for API calls at scale.

Chunking Strategy

Chunking is where most RAG implementations fail. The wrong chunk size means retrieving irrelevant context or missing critical information.

# Naive chunking - DON'T DO THIS
chunks = [text[i:i+1000] for i in range(0, len(text), 1000)]

# Better: Semantic chunking with overlap
from langchain.text_splitter import RecursiveCharacterTextSplitter

splitter = RecursiveCharacterTextSplitter(
    chunk_size=512,
    chunk_overlap=50,
    separators=["\n\n", "\n", ". ", " ", ""]
)
chunks = splitter.split_text(document)

Optimal chunk size depends on content type:

The overlap prevents context from being split mid-sentence. Without overlap, you get chunks that end "The key consideration is" and start "implementing proper authentication"... neither useful alone.

Update Patterns

Production systems need incremental updates. Re-embedding your entire corpus for every change doesn't scale.

class EmbeddingManager:
    def __init__(self, db, embedder):
        self.db = db
        self.embedder = embedder

    def upsert_document(self, doc_id: str, content: str, metadata: dict):
        # Hash content to detect changes
        content_hash = hashlib.sha256(content.encode()).hexdigest()

        existing = self.db.get_document(doc_id)
        if existing and existing.content_hash == content_hash:
            return  # No change, skip embedding

        # Generate embedding only for changed content
        embedding = self.embedder.embed(content)

        self.db.upsert(
            id=doc_id,
            embedding=embedding,
            metadata={**metadata, "content_hash": content_hash}
        )

    def delete_document(self, doc_id: str):
        self.db.delete(doc_id)

Track content hashes to avoid re-embedding unchanged documents. Batch updates during off-peak hours. Use queues for async embedding of new content.

●RAG Architecture Patterns

Retrieval-Augmented Generation comes in levels of sophistication. Most tutorials show naive RAG. Production requires more.

Naive RAG

Query → Embed → Vector Search → Top-K Results → LLM → Response

Works for demos. Falls apart when:

• Users ask compound questions
• Relevant information spans multiple documents
• Query terms don't match document vocabulary
• Top-K results are semantically similar but redundant

Advanced RAG with Re-ranking

Query → Embed → Vector Search (Top-20) → Re-ranker → Top-5 → LLM → Response

The re-ranker is a cross-encoder that scores query-document pairs with higher accuracy than vector similarity.

from sentence_transformers import CrossEncoder

# Load re-ranker
reranker = CrossEncoder('cross-encoder/ms-marco-MiniLM-L-12-v2')

def retrieve_with_rerank(query: str, k: int = 5):
    # Retrieve more candidates than needed
    candidates = vector_db.search(query, limit=20)

    # Score each candidate with the re-ranker
    pairs = [(query, doc.content) for doc in candidates]
    scores = reranker.predict(pairs)

    # Sort by re-ranker score and take top-k
    ranked = sorted(zip(candidates, scores), key=lambda x: x[1], reverse=True)
    return [doc for doc, score in ranked[:k]]

Re-ranking adds 50-200ms latency but dramatically improves precision. For queries where accuracy matters more than speed, it's non-negotiable.

Query Expansion

Users don't always phrase queries optimally. Query expansion generates variations to improve recall.

def expand_query(query: str) -> list[str]:
    expansion_prompt = f"""Generate 3 alternative phrasings of this query
    that might match relevant documents:

    Query: {query}

    Return as JSON array of strings."""

    response = llm.generate(expansion_prompt)
    variations = json.loads(response)

    return [query] + variations

def retrieve_expanded(query: str, k: int = 5):
    expanded = expand_query(query)

    all_results = []
    for q in expanded:
        results = vector_db.search(q, limit=k)
        all_results.extend(results)

    # Deduplicate and rank
    return deduplicate_and_rank(all_results)[:k]

Hypothetical Document Embedding (HyDE)

Instead of embedding the query, embed a hypothetical answer... then find documents similar to that answer.

def hyde_retrieve(query: str, k: int = 5):
    # Generate hypothetical answer
    hypothesis_prompt = f"""Write a detailed paragraph that would answer
    this question. Do not say "I don't know" - provide a plausible answer:

    Question: {query}"""

    hypothesis = llm.generate(hypothesis_prompt)

    # Embed the hypothesis, not the query
    hypothesis_embedding = embedder.embed(hypothesis)

    # Search for documents similar to the hypothesis
    return vector_db.search_by_vector(hypothesis_embedding, limit=k)

HyDE works remarkably well for technical domains where query vocabulary differs from document vocabulary. The LLM bridges the semantic gap.

Parent Document Retrieval

Retrieve small chunks for precision, but return larger context for the LLM.

class ParentDocumentRetriever:
    def __init__(self, chunk_db, parent_db):
        self.chunk_db = chunk_db
        self.parent_db = parent_db

    def retrieve(self, query: str, k: int = 5):
        # Search in chunk database for precision
        chunks = self.chunk_db.search(query, limit=k * 2)

        # Get unique parent documents
        parent_ids = list(set(c.parent_id for c in chunks))

        # Return full parent documents for context
        return [self.parent_db.get(pid) for pid in parent_ids[:k]]

Small chunks (128-256 tokens) embed with higher specificity. But feeding the LLM a 128-token snippet loses surrounding context. Parent retrieval solves this: search on chunks, return the full document or section.

●Prompt Engineering at Scale

Prompts are code. Treat them accordingly.

Version Control

# prompts/rag_answer_v3.py
RAG_ANSWER_PROMPT = """You are a helpful assistant answering questions based
on the provided context.

Context:
{context}

Question: {question}

Instructions:
- Answer based ONLY on the provided context
- If the context doesn't contain the answer, say "I don't have information about that"
- Cite specific parts of the context when relevant
- Be concise but complete

Answer:"""

PROMPT_VERSION = "v3.2.1"
PROMPT_HASH = hashlib.sha256(RAG_ANSWER_PROMPT.encode()).hexdigest()[:8]

Track prompt versions in logs. When quality degrades, you need to know which prompt version was active.

A/B Testing Prompts

class PromptRouter:
    def __init__(self):
        self.prompts = {
            "control": RAG_ANSWER_PROMPT_V3,
            "variant_a": RAG_ANSWER_PROMPT_V4_CONCISE,
            "variant_b": RAG_ANSWER_PROMPT_V4_DETAILED,
        }
        self.weights = {"control": 0.8, "variant_a": 0.1, "variant_b": 0.1}

    def get_prompt(self, user_id: str) -> tuple[str, str]:
        # Deterministic assignment based on user
        bucket = hash(user_id) % 100

        if bucket < 80:
            variant = "control"
        elif bucket < 90:
            variant = "variant_a"
        else:
            variant = "variant_b"

        return self.prompts[variant], variant

Log the variant with every response. Measure quality metrics (thumbs up/down, task completion) per variant. Promote winners, iterate on losers.

Prompt Testing

Unit tests for prompts:

def test_rag_prompt_handles_no_context():
    context = "The document discusses weather patterns in Antarctica."
    question = "What is the capital of France?"

    response = llm.generate(RAG_ANSWER_PROMPT.format(
        context=context,
        question=question
    ))

    assert "don't have information" in response.lower() or \
           "not in the context" in response.lower()

def test_rag_prompt_cites_context():
    context = "The Eiffel Tower is 330 meters tall."
    question = "How tall is the Eiffel Tower?"

    response = llm.generate(RAG_ANSWER_PROMPT.format(
        context=context,
        question=question
    ))

    assert "330" in response

Run prompt tests on every deployment. LLM behavior changes with model updates... catch regressions early.

●Cost Management

LLM costs compound faster than most teams expect. A "reasonable" $50/day prototype becomes $1,500/month becomes $18,000/year.

Token Optimization

Every token costs money. Optimize aggressively.

def optimize_context(documents: list[str], max_tokens: int = 4000) -> str:
    # Sort by relevance (assuming already ranked)
    # Truncate to fit token budget

    token_count = 0
    selected = []

    for doc in documents:
        doc_tokens = count_tokens(doc)
        if token_count + doc_tokens > max_tokens:
            # Truncate this document to fit
            remaining = max_tokens - token_count
            truncated = truncate_to_tokens(doc, remaining)
            if truncated:
                selected.append(truncated)
            break

        selected.append(doc)
        token_count += doc_tokens

    return "\n\n".join(selected)

Semantic Caching

Many queries are semantically equivalent. "What is the return policy?" and "How do I return an item?" should hit the same cache.

class SemanticCache:
    def __init__(self, vector_db, similarity_threshold: float = 0.95):
        self.db = vector_db
        self.threshold = similarity_threshold

    def get(self, query: str) -> Optional[str]:
        query_embedding = embedder.embed(query)

        results = self.db.search(
            vector=query_embedding,
            limit=1,
            filter={"type": "cache"}
        )

        if results and results[0].score > self.threshold:
            return results[0].payload["response"]

        return None

    def set(self, query: str, response: str):
        query_embedding = embedder.embed(query)

        self.db.upsert(
            id=f"cache_{hashlib.sha256(query.encode()).hexdigest()[:16]}",
            vector=query_embedding,
            payload={"query": query, "response": response, "type": "cache"}
        )

Semantic caching can reduce LLM calls by 40-60% for applications with repetitive query patterns... support chatbots, FAQ systems, documentation search.

Model Routing

Not every query needs GPT-4.

class ModelRouter:
    def __init__(self):
        self.classifier = load_complexity_classifier()

    def route(self, query: str, context: str) -> str:
        complexity = self.classifier.predict(query, context)

        if complexity < 0.3:
            return "gpt-3.5-turbo"  # $0.50/1M tokens
        elif complexity < 0.7:
            return "gpt-4o-mini"    # $0.15/1M tokens
        else:
            return "gpt-4o"         # $2.50/1M tokens

Train a small classifier on query complexity. Route simple queries to cheap models. Reserve expensive models for complex reasoning.

Cost Breakdown by Component

Typical RAG system cost distribution:

Focus optimization effort proportional to cost share. LLM calls dominate... optimize there first.

●Reliability Patterns

Production LLM systems fail in novel ways. Plan for it.

Fallback Chains

class LLMClient:
    def __init__(self):
        self.primary = OpenAIClient()
        self.fallback = AnthropicClient()
        self.emergency = LocalLlamaClient()

    async def generate(self, prompt: str) -> str:
        try:
            return await asyncio.wait_for(
                self.primary.generate(prompt),
                timeout=10.0
            )
        except (TimeoutError, RateLimitError, APIError) as e:
            logger.warning(f"Primary LLM failed: {e}")

        try:
            return await asyncio.wait_for(
                self.fallback.generate(prompt),
                timeout=15.0
            )
        except (TimeoutError, RateLimitError, APIError) as e:
            logger.warning(f"Fallback LLM failed: {e}")

        # Emergency: local model, slower but always available
        return await self.emergency.generate(prompt)

Never depend on a single LLM provider. OpenAI has outages. Rate limits hit at the worst times. A fallback chain keeps your application running.

Rate Limiting

from asyncio import Semaphore
from collections import defaultdict
import time

class RateLimiter:
    def __init__(self, rpm: int = 60, tpm: int = 100000):
        self.rpm = rpm
        self.tpm = tpm
        self.request_times = []
        self.token_counts = []
        self.semaphore = Semaphore(10)  # Max concurrent requests

    async def acquire(self, estimated_tokens: int):
        async with self.semaphore:
            now = time.time()

            # Clean old entries
            self.request_times = [t for t in self.request_times if now - t < 60]
            self.token_counts = [
                (t, c) for t, c in self.token_counts if now - t < 60
            ]

            # Check limits
            if len(self.request_times) >= self.rpm:
                wait_time = 60 - (now - self.request_times[0])
                await asyncio.sleep(wait_time)

            total_tokens = sum(c for _, c in self.token_counts)
            if total_tokens + estimated_tokens > self.tpm:
                await asyncio.sleep(1)  # Back off

            self.request_times.append(now)
            self.token_counts.append((now, estimated_tokens))

Implement client-side rate limiting. Don't rely on hitting API limits... you'll get errors and degraded service.

Graceful Degradation

class RAGService:
    async def answer(self, query: str) -> Response:
        try:
            # Full RAG pipeline
            context = await self.retrieve(query)
            answer = await self.llm.generate(query, context)
            return Response(answer=answer, source="rag")

        except VectorDBTimeout:
            # Fallback: LLM without context
            answer = await self.llm.generate(query, context=None)
            return Response(
                answer=answer,
                source="llm_only",
                warning="Could not retrieve context"
            )

        except LLMTimeout:
            # Fallback: return relevant documents without synthesis
            context = await self.retrieve(query)
            return Response(
                answer=None,
                documents=context,
                source="retrieval_only",
                warning="Could not generate answer"
            )

        except Exception:
            # Last resort: canned response
            return Response(
                answer="I'm having trouble processing your request. Please try again.",
                source="fallback"
            )

Define degradation tiers. Something is always better than an error page.

●Monitoring and Observability

LLMs fail silently. Quality degrades without errors. You need specialized monitoring.

Key Metrics

# Track these for every LLM call
metrics = {
    "latency_ms": response_time,
    "tokens_input": prompt_tokens,
    "tokens_output": completion_tokens,
    "cost_usd": calculate_cost(prompt_tokens, completion_tokens, model),
    "model": model_name,
    "prompt_version": prompt_hash,
    "cache_hit": was_cached,
    "fallback_used": used_fallback,
}

Dashboard essentials:

• P50/P95/P99 latency by endpoint
• Token usage over time (cost proxy)
• Cache hit rate (should be > 40% for repetitive use cases)
• Fallback rate (spikes indicate provider issues)
• Error rate by error type

Hallucination Detection

Automated hallucination detection is imperfect but necessary.

class HallucinationDetector:
    def check(self, query: str, context: str, response: str) -> float:
        # Check 1: Does response contain claims not in context?
        claims = self.extract_claims(response)
        unsupported = [c for c in claims if not self.claim_in_context(c, context)]
        unsupported_ratio = len(unsupported) / max(len(claims), 1)

        # Check 2: Confidence calibration
        confidence_prompt = f"""Rate your confidence that this answer is
        correct based ONLY on the provided context.

        Context: {context}
        Answer: {response}

        Return only a number 0-100."""

        confidence = self.llm.generate(confidence_prompt)

        # Check 3: Self-consistency (generate multiple times, check agreement)
        variants = [self.regenerate(query, context) for _ in range(3)]
        consistency = self.measure_consistency([response] + variants)

        # Combine signals
        hallucination_score = (
            0.4 * unsupported_ratio +
            0.3 * (1 - float(confidence) / 100) +
            0.3 * (1 - consistency)
        )

        return hallucination_score

Flag responses with high hallucination scores for human review. Track hallucination rate over time as a quality metric.

User Feedback Loop

@app.post("/api/feedback")
async def submit_feedback(
    response_id: str,
    helpful: bool,
    feedback_text: Optional[str] = None
):
    # Store feedback
    await db.feedback.create({
        "response_id": response_id,
        "helpful": helpful,
        "feedback_text": feedback_text,
        "timestamp": datetime.utcnow()
    })

    # Update quality metrics
    await metrics.increment(
        "feedback_thumbs_up" if helpful else "feedback_thumbs_down"
    )

    # Flag for review if negative
    if not helpful:
        response = await db.responses.get(response_id)
        await review_queue.add({
            "response": response,
            "feedback": feedback_text
        })

Thumbs up/down on every response. Review negative feedback weekly. This is your ground truth for quality.

●Conclusion

Production LLM integration is infrastructure engineering, not prompt magic.

The systems that work:

1. Choose boring vector databases until you have data proving you need exotic ones. pgvector handles most use cases.

2. Invest in retrieval quality. Re-ranking, query expansion, and parent document retrieval matter more than model selection.

3. Version everything. Prompts, embeddings, models. When quality degrades, you need to know what changed.

4. Cache aggressively. Semantic caching cuts costs by 40-60% for repetitive workloads.

5. Build fallback chains. Single points of failure become actual failures.

6. Monitor for silent degradation. Hallucination rates, user feedback, latency percentiles.

The teams that ship AI features successfully treat LLM integration as a systems problem, not a prompting problem. They build infrastructure for reliability, observability, and cost control first... then iterate on quality.

Start with the simplest architecture that works: pgvector + text-embedding-3-small + GPT-4o-mini + basic RAG. Add complexity only when you have data showing you need it.

Everything else is engineering theater.

Building LLM-powered features? I help teams architect AI integrations that actually work in production... reliable, cost-effective, and observable.

• AI Integration for SaaS ... Production AI that scales
• Technical Advisor for Startups ... LLM architecture guidance
• AI Integration for Healthcare ... HIPAA-ready AI infrastructure

●Continue Reading

This post is part of the AI-Assisted Development Guide ... covering code generation, LLM architecture, prompt engineering, and cost optimization.

More in This Series

• AI-Assisted Development: Navigating the Generative Debt Crisis ... The hidden costs of AI-generated code
• Prompt Engineering for Developers ... Getting better LLM results
• AI Code Review ... Catching what LLMs miss
• Building AI Features Users Want ... Product strategy for AI
• AI Cost Optimization ... APIs vs self-hosting vs fine-tuning

Integrating AI into your product? Work with me on your AI architecture.
